Description
Technical Parameters
ISO9809-1 133-3.0 (3.4-7.9)L-200MPa cylinder
Small Cylinder is a mechanical device that uses the power of compressed gas to generate force in reciprocating linear motion.
Cylinders are quieter, cleaner, and do not require a lot of space to store fluid.
The cylinder has a diameter of 10mm, a stroke of 100mm, and a pressure of 1Mpa.
High Quality: The cylinder is made of high-quality stainless steel and has a long service life.
The body of the Small Cylinder is made of high-quality aluminum alloy, which is high in strength, non-deformable, impact-resistant and wear-resistant.
It adopts a unique sealing structure, and the two ends are connected to the cylinder by riveting. Before shipping the goods to you, we will check to make sure that there is no leakage in the cylinder seal.
The cylinder is a mechanical device that uses the power of compressed gas to generate force in reciprocating linear motion.
The pneumatic actuator, The pneumatic cylinder is a mechanical devices which use the power of compressed gas to produce a force in a reciprocating linear motion.
The pneumatic air cylinder, Made of high quality stainless steel, the pneumatic cylinder has long service life.
This is a double-acting cylinder which uses the force of air to move in both extend and retract strokes.
It has 10mm cylinder diameter and 30mm stroke, the pressure is 0.15Mpa~1Mpa.
Pneumatic cylinder is quieter, cleaner, and do not require large amounts of space for fluid storage.
Hot Tags: small cylinder, China small cylinder manufacturers, suppliers, factory, Medical Oxygen Tank, ISO9809 2 TPED Cylinder, Billet Pierced Cylinder, 27L Cylinder, 50L Cylinder, Small Acetylene Cylinders
|
No. |
Process |
Type |
OD(mm) |
V(L) |
WP(Bar) |
|
1 |
Billet |
ISO9809 219-(20-40)L-166.7 |
219 |
20-40 |
166.7 |
|
2 |
ISO9809 229-(40-50)L-150 |
229 |
40-50 |
150 |
|
|
3 |
ISO9809 229-(20-50)L-166.7 |
229 |
20-50 |
166.7 |
|
|
4 |
ISO9809 229-(20-50)L-200 |
229 |
20-50 |
200 |
|
|
5 |
ISO9809 229-(20-50)L-230 |
229 |
20-50 |
230 |
|
|
6 |
ISO9809 229-(20-50)L-300 |
229 |
20-50 |
300 |
|
|
7 |
ISO9809 232-(23-50)L-147 |
232 |
23-50 |
147 |
|
|
8 |
Tube |
ISO9809 133-(3.4-7.9)L-200 |
133 |
3.4-7.9 |
200 |
|
9 |
ISO9809 138-(4.5-12)L-200 |
138 |
4.5-12 |
200 |
|
|
10 |
ISO9809 140-(4.5-12)L-200 |
140 |
4.5-12 |
200 |
|
|
11 |
ISO9809 152-(6-15)L-200 |
152 |
6-15 |
200 |
|
|
12 |
ISO9809 165-(7-15)L-200 |
165 |
7-15 |
200 |
|
|
13 |
ISO9809 178-(9.6-24)L-174 |
178 |
9.6-24 |
174 |
|
|
14 |
ISO9809 188-(12-30)L-154 |
188 |
12-30 |
154 |
|
|
15 |
ISO9809 203-(10-40)L-200 |
203 |
10-40 |
200 |
|
|
16 |
ISO9809 219-(20-43.2)L-166.7 |
219 |
20-43.2 |
166.7 |
|
|
17 |
ISO9809 229-(20-50)L-200 |
229 |
20-50 |
200 |
|
|
18 |
ISO9809 229-(20-51)L-230 |
229 |
20-51 |
230 |
|
|
19 |
ISO9809 232-(20-51)L-166.7 |
232 |
20-51 |
166.7 |
|
|
20 |
ISO9809 232-(30-50)L-200 |
232 |
30-50 |
200 |
|
|
21 |
ISO9809 267-(50-82.5)L-166.7 |
267 |
50-82.5 |
166.7 |
|
|
22 |
ISO9809 279-(40-90)L-200 |
279 |
40-90 |
200 |
|
|
23 |
ISO9809 356-(100-150)L-200 |
356 |
100-150 |
200 |
|
|
24 |
ISO9809 356-(85-150)L-200A |
356 |
85-150 |
200 |
Note：A：Convex.
